Renogy Core Series Mini 12V 200A Deep Cycle Lithium Iron Phosphate Battery

Product Description

Note: eBay's compatibility table is not accurate in some cases. Please refer to the following information we have provided for you.
Copyright © 2014 - 2025 Superspares. All rights reserved.

LOCAL PICK UP ONLY!

Please note at the moment our couriers can only deliver to business addresses, if you put a residential address we'll contact you for a business address for FREIGHT items. We can get it dropped at nearby depots for collection if that is more convenient.Calculated shipping price at checkout is for Metro Brisbane, Sydney, Melbourne ONLY. If you are out of these areas either contact us for freight quote or we will call you prior to shipping for the extra freight charge.

Content: 1 x Renogy Core Series Mini 12V 200A Deep Cycle Lithium Iron Phosphate Battery

Specifications:

General
Rated Capacity (0.5C, 25°C): 200Ah
Nominal Voltage: 12.8V
Energy: 1280Wh
Cycle Life (0.5C/1C, 25°C): 5000 Cycles (80% DOD, 80% EOL)

Discharging Parameters
Maximum Continuous Discharge Current: 200A
Peak Discharge Current: 380A@10s

Charging Parameters
Voltage Range: 10V to 14.6V
Maximum Continuous Charge Current: 100A

Temperature Parameters
Operation Temperature Range Charge: 32°F to 131°F (0°C to 55°C)
Operation Temperature Range Discharge: -4°F to 149°F (-20°C to 65°C)
Storage Temperature Range: -4°F to 140°F (-20°C to 60°C)
Operation Relative Humidity: 5% to 95%

Mechanical Specifications
Dimension (L x W x H): 15.12¡Á7.64¡Á9.96 in/384¡Á194¡Á253 mm
Weight: 42.44 lbs / 19.25 kg
Terminal Bolt Size: M8¡Á1.25¡Á12 mm & M8¡Á1.25¡Á16 mm
Protection Rating: IP65

Certifications: MSDS, UN38.3, FCC, CE, PSE, RCM, IC, RoHS, and UKCA
Warranty: 5-year material warranty

Smaller than ever! 1/3 smaller than 12V 200Ah lead-acid. A 200A BMS, more robust than a 100A. Low-temp cut-off (charge & discharge). IP65 waterproof & vibration-resistant for enhanced outdoor performance. Certified by FCC, UN38.3, ROHS, UKCA and more. 5-year warranty. Works with a Renogy 300A Battery Shunt for Remote Monitoring.

Smaller, Sleeker, Still Renogy Strong. Power up with compact confidence! The Renogy 12V 200Ah Core Mini LiFePO4 Battery is 21% smaller than its counterparts while maintaining a robust 200A BMS plus a low-temperature cut-off for enhanced protection. Perfect for both travel and home use, it's the ideal solution for versatile power demands.

Renogy is a renewable energy company specializing in solar power solutions, with a focus on making clean energy accessible and affordable. They offer a range of solar panels, inverters, batteries, and other components for both on-grid and off-grid applications. Renogy is known for its high-quality products, expert advice, and commitment to customer satisfaction.
